RLX2-IHx Series ♦ 802.11a, b, g, n
Industrial Hotspots
Temperature
Retries(%)
Uptime
Product
Image Ver
Tx Pkts/Sec
Rx Pkts/Sec
ProSoft Technology, Inc.
Displays the internal temperature of the radio as measured on the circuit
board in degrees Celsius. Note that internal measured temperature always
exceeds the ambient external temperature.
Displays the ratio of packet re-transmission to total packet transmissions
during the last five-second interval for the radio.
Displays the amount of time the radio has been running since the last
power cycle or reset; for example, 1d,4h,13m,25s.
Displays the model number of the RLX2 radio; for example RLX2-IHA,
RLX2-IHG, RLX2-IHFN, RLX2-IHFN-W, or RLX2-IHW.
Displays the name of the image file loaded into the radio; for example,
RLX2_ 0036_R.
V
Displays a moving average of transmitted data packets/second. For
Repeater radios, this shows the data packet rate transmitted over the
radio link to the Parent radio. For Master radios, this is the transmitted
data packet rate sum on all the Master's radio links.
Displays a moving average of received data packets/second. For
Repeater radios, this shows the data packet rate received over the radio
link to the Parent radio. For Master radios, this is the received data packet
rate sum on all the Master's radio links.
Using the IH Browser to Manage your Radios
User Manual
Page 128 of 248
