RLX2.STATUS.RxRadioThroughput
RLX2.STATUS.Uptime
RLX2.STATUS.Linktime
RLX2.STATUS.TxPacketRate
RLX2.STATUS.RxPacketRate
RLX2.STATUS.ModuleName
RLX2.STATUS.ProductName
RLX2.STATUS.ImageVerStr
RLX2.STATUS.TxGood
RLX2.STATUS.RxGood
RLX2.STATUS.TxBad
RLX2.STATUS.RxBad
RLX2.STATUS.TxDirectedFrames
RLX2.STATUS.TxMulticastFrames
RLX2.STATUS.TxBroadcastFrames
RLX2.STATUS.RxDirectedFrames
RLX2.STATUS.RxMulticastFrames
RLX2.STATUS.RxBroadcastFrames
RLX2.STATUS.RxCRCErr
The following additional array elements are populated if the RLX2 is running firmware
greater or equal to RLX2_v0038_R.
RLX2.STATUS.Retries
RLX2.STATUS.Utilization
RLX2.STATUS.ChannelWidth
RLX2.STATUS.Antennas
RLX2.STATUS.TxRate
RLX2.STATUS.TxBitRate
RLX2.STATUS.TxBcastRate
RLX2.STATUS.TxMcastRate
RLX2.STATUS.ReservedXX
ProSoft Technology, Inc.
If bit 15 = 1, then bits 0 to 14 represent the
throughput in 100 kilobits/sec.
INT If bit 15 = 0, then bits 0 to 14 represent the
throughput in kilobits/sec.
If bit 15 = 1, then bits 0 to 14 represent the
throughput in 100 kilobits/sec.
DINT This is the amount of time the radio has been
running since power up in seconds
DINT The time the radio has been linked in seconds
DINT Packets per second transmitted on air
DINT Packets per seconds received on air
SINT[32] The name of the radio
Name of product
SINT[32]
SINT[28] Firmware version loaded in device
DINT Number of Good Transmitted Frames
DINT Number of Good Received Frames
DINT Number of Bad Transmitted Frames
DINT Number of Bad Received Frames
Number of Transmitted Directed Frames
DINT
Number of Transmitted Multicast Frames
DINT
DINT Number of Transmitted Broadcast Frames
DINT Number of Received Directed Frames
DINT Number of Received Multicast Frames
DINT Number of Received Broadcast Frames
Number of CRC Errors
DINT
SINT The radio retransmission percentage (0-100%)
Retries = # retransmissioins / total transmissions
SINT The percentage of time the media is detected as
busy. (0-100%)
Configured channel width (20 or 40 MHz)
SINT
SINT Antenna Status
xxxx xxyy, where yy = # of Enabled Antennas
x, N/A
INT Encoded current Tx Rate to Parent (Client/Repeater
mode only)
0x800y, where y => MCSy, or
0x0zzz, where zzz = bit rate in 100 kb/s units
INT Decoded actual signaling bit rate on the air in 100
kb/s units
INT Broadcast (ff:ff:ff:ff:ff:ff) packet rate being sent to
radio. Value calculated every 5 seconds.
INT Multicast (01:xx:xx:xx:xx:xx) packet rate being sent
to radio. Value calculated every 5 seconds.
16 DINT variables reserved for future use.
