Chapter 2: Jumpers and Connectors
Internal Connectors
Fan Connector
Connector type: 1x4 4-pin wafer
Connector location: FAN1
1
4
Pin
Definition
1
GND
2
12V
3
FAN1_IN
4
FAN1_PWM_R
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
RTC Battery Holder
Connector type: 1x2 2-pin header
Connector location: BAT1
1 2
Pin
Definition
1
GND
2
3V_BATT
17
