Chapter 2: Jumpers and Connectors

Internal Connectors

Power Button Header

Connector type: 1x2 2-pin header
Connector location: JPWRBTN1
1 2
Pin Definition
1 FP_PWRBTN_R_N
2 GND
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.

System Fan Connectors

Connector type: 2x2 4-pin header
Connector location: CN3, CN4 and CN5
1 3
2 4
Pin Definition
1 GND
3 SYS_FAN3_PWM
9
Pin Definition
2 SYS_FAN3_TACH_P
4 P12V
