Product Specifications - INVT Goodrive350A Series Operation Manual

Goodrive350A series high-performance multifunction VFD
R
S
T
PE
R
S
T
PE
Figure 3.4 Main circuit diagram for 132G/160P and higher models
Note:

132G/160P and higher models can be connected to external DC reactors. Before connection,
take off the copper bar between P1 and (+). 075G/090P and higher models can be connected to
external braking units. DC reactors and braking units are optional parts.

018G/022P–110G/132P models are equipped with built-in DC reactors.

037G/045P and lower models carry built-in braking units. Braking units are optional parts for
045G/055P–055G/075P models and they can be built in or externally connected to the models.

3.3 Product specifications

Function description
Power input
Input frequency (Hz)
Power
（+）
（-）
Figure 3.3 Main circuit diagram for 045G/055P–110G/132P
DC reactor
P1
Input voltage (V)
Input current (A)
Output voltage (V)
（+）
（-）
AC 3PH 380V (-15%)–440V (+10%)
See "Product ratings".
50Hz or 60Hz, allowable range: 47–63Hz
0–Input voltage
-9-
Product overview
W
PE
Specification
U
V
U
V
W
PE
