Appendix A Expansion cards
A.1 Model definition
Field
①
②
③
④
⑤
⑥
EC-PG 5 01-05 B
①
Field description
Product category
Card category
Technical version
Distinguishing code
Working power
Expansion card version
② ③ ④ ⑤ ⑥
EC: Expansion card
IC: IoT card
IO: IO card
PC: Programmable card
PG: PG card
PS: Power supply card
TX: Communication card
Indicates the generation of technical version by
using an odd number. For example, 1, 3, 5, and 7
indicate the 1st, 2nd, 3rd and 4th generations of
technical version.
01: Incremental PG card + frequency-divided output
02: Sine/Cosine PG card + pulse direction setting +
frequency-divided output
03: UVW PG interface + pulse direction setting +
frequency-divided output
04: Resolver PG interface + pulse direction setting +
frequency-divided output
05: Incremental PG card + pulse direction setting +
frequency-divided output
06: Absolute PG interface + pulse direction setting +
frequency-divided output
07: Simple incremental PG card
00: Passive
05: 5V
12: 12–15 V
24: 24 V
Empty: Version A
B: Version B
C: Version C
-339-
Naming example
Expansion cards
