INVT Goodrive350A Series Operation Manual page 266

Goodrive350A series high-performance multifunction VFD
Function
Name
code
P24.02 Encoder direction
Detection time of
P24.03
encoder offline fault
Detection time of
P24.04 encoder reversal
fault
Filter times of
P24.05
encoder detection
Speed ratio
between encoder
P24.06
mounting shaft and
motor
Control parameters
P24.07
of SM
Description
0x000–0x111
Ones: AB direction
0: Forward
1: Reverse
Tens: Z pulse direction (reserved)
0: Forward
1: Reverse
Hundreds: CD/UVW pole signal direction
0: Forward
1: Reverse
0.0–10.0s
0.0–100.0s
Setting range: 0x00–0x99
Ones place: Low-speed filter time,
corresponds to 2^(0–9)×125μs.
Tens place: High-speed filter times,
corresponds to 2^(0–9)×125μs.
You need to set the function code when the
encoder is not installed on the motor shaft and
the drive ratio is not 1.
Setting range: 0.001–65.535
0x0000–0xFFFF
Bit0: Enable/disable encoder input filter
0: No filter
1: Filter
Bit1: Encoder signal filter mode
0: Self-adaptive filter
1: Use P24.18 filter parameters
Bit2: Enable/disable encoder
frequency-division output filter
0: No filter
1: Filter
Bit3: Enable/disable pulse reference
frequency-division output filter
0: No filter
-261-
Function parameter list
Default
Modify
value
◎
0x000
○
2.0s
○
0.8s
○
0x33
○
1.000
○
0x0003
