Goodrive350A series high-performance multifunction VFD
16:02:35 Fwd
Output Freq
P17.01 Hz
Set Freq
P17.00 Hz
DC Bus Volt
P17.11 V
Parameter
Press or to switch between different display styles, including list display style and progress
bar display style.
16:02:35 Fwd
DC Bus Volt
P17.11 V
Outp Volt
P17.03
Outp Cur
P17.04
Parameter
In running state, multiple kinds of state parameters can be displayed. The running display parameter
list is user defined, and each state variable function code can be added to the running display
parameter list as needed. A function code which has been added to the running display parameter list
can also be deleted or shifted.
5.3.3 Displaying fault information
The VFD enters fault alarm display state once fault signal is detected, and the keypad displays fault
code and fault information with TRIP indicator on the keypad turning on. Fault reset operation can be
carried out via STOP/RST key, control terminal or communication command.
The fault code will be kept displaying until fault is removed.

5.4 Operating the VFD through the keypad

You can perform various operations on the VFD by using the keypad, including entering/exiting
Local Run GD350A
50.00
50.00
540.0
About
Menu
Figure 5.5 Running state parameters
Local Run GD350A
540.00
540.0
378
About
Menu
Figure 5.6 Running parameter display state
16:02:35
Fwd
Present fault type:
Fault code：
19：Current detection fault (ItE)
Back
Figure 5.7 Displaying a fault
16:02:35 Fwd
Set Freq
P17.00 Hz
DC Bus Volt
P17.11 V
Output Volt
P17.03 V
Parameter
16:02:35
Fwd
DC Bus Volt
V
0.0
Back
Local GD350A
Fault
19
Home
OK
-35-
Basic operation guidelines
Local Run GD350A
50.00
540.0
378
About
Menu
Local Run GD350A
540.00
2000.0
Home
