INVT Goodrive350A Series Operation Manual page 162

Goodrive350A series high-performance multifunction VFD
Function
Name
code
through keypad in
torque control
Setting source of
P03.18 electromotive
torque upper limit
Setting source of
P03.19 braking torque
upper limit
Electromotive
P03.20 torque upper limit
set through keypad
P03.21 Braking torque
Description
0: Keypad (P03.20)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus/Modbus TCP communication
6: PROFIBUS/CANopen/DeviceNet
communication
7: Ethernet communication
8: Pulse frequency HDIB
9: EtherCAT/PROFINET/EtherNet IP
communication
10: Programmable card
11: Reserved
Note: For these settings, 100% corresponds
to the motor rated current.
0: Keypad (P03.21)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus/Modbus TCP communication
6: PROFIBUS/CANopen/DeviceNet
communication
7: Ethernet communication
8: Pulse frequency HDIB
9: EtherCAT/PROFINET/EtherNet IP
communication
10: Programmable card
11: Reserved
Note: For these settings, 100% corresponds
to the motor rated current.
Used to set torque limits.
Setting range: 0.0–300.0% (of the motor rated
current)
-157-
Function parameter list
Default Modify
○
0
○
0
○
180.0%
○
180.0%
