Goodrive350A series high-performance multifunction VFD
Function
Name
code
P05.07 Reserved
Input terminal
P05.08
polarity
Digital input filter
P05.09
time
Virtual terminal
P05.10
setting
Description
63: Enable servo
64: Limit of forward run
65: Limit of reverse run
66: Zero out encoder counting
67: Pulse increase
68: Enable pulse superimposition
69: Pulse decrease
70: Electronic gear selection
71: Switch to master
72: Switch to slave
73: Reset the roll diameter
74: Switch winding/unwinding
75: Pre-drive
76: Disable roll diameter calculation
77: Clear alarm display
78: Manual braking
79: Trigger forced feeding interrupt
80: Initial roll diameter 1
81: Initial roll diameter 2
82: Trigger fire mode control
83: Switch tension PID parameters
84–95: Reserved
Used to set the polarity of input terminals.
When a bit is 0, the input terminal is positive;
when a bit is 1, the input terminal is negative.
0x000–0x3F
Used to set the filter time for S1–S4, HDIA,
and HDIB. In strong interference cases,
increase the value to avoid maloperation.
0.000–1.000s
0x00–0x3F (0: disable, 1: enable)
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: HDIA virtual terminal
BIT5: HDIB virtual terminal
-172-
Function parameter list
Default Modify
○
0x00
○
0.010s
◎
0x00
