Goodrive350A series high-performance multifunction VFD
Function description
Extended interfaces
running environment
Other
resolution
Analog input
Analog output
Digital input
Digital output
Relay output
Mounting method
Temperature of
Ingress protection
rating
Pollution degree
Cooling method
Braking unit
EMC filter
2 inputs; AI1: 0–10V/0–20mA; AI2: -10–10V
1 input; AO1: 0–10V/0–20mA
Four regular inputs; max. frequency: 1kHz; internal
impedance: 3.3kΩ
Two high-speed inputs; max. frequency: 50kHz;
supporting quadrature encoder input; with speed
measurement function
One high-speed pulse output; max. frequency: 50kHz
One Y terminal open collector output
Two programmable relay outputs
RO1A: NO; RO1B: NC; RO1C: common
RO2A: NO; RO2B: NC; RO2C: common
Contact capacity: 3A/AC250V, 1A/DC30V
Three extended interfaces: SLOT1, SLOT2, and
SLOT3 (control board of above 7.5kW)
Supporting PG cards, programmable expansion cards,
communication cards, I/O cards and so on
Wall mounting, floor mounting, and flange mounting
-10 – +50° C; derating is required if the ambient
temperature exceeds 40° C
IP20
Degree 2
Forced air cooling
The VFD models of 037G/045P and lower contain
built-in braking units. The braking units are optional
parts for the 045G/055P–055/075P VFD models, and
the braking units can be built in or externally
connected.
The transmission of the VFD meets the IEC/EN
61800-3 C3 requirements.
When optional filters are connected externally, the
transmission of the VFD can meet the IEC/EN 61800-3
C2 requirements.
Note: Comply with the EMC requirements and the
technical requirements for the motors and motor cables
in the appendix in the manual.
-11-
Product overview
Specification
