INVT Goodrive350A Series Operation Manual page 244

Goodrive350A series high-performance multifunction VFD
Function
Name
code
compensation
torque
P17.47 Motor pole pairs
VFD overload count
P17.48
value
Frequency set by A
P17.49
source
Frequency set by B
P17.50
source
PID proportional
P17.51
output
P17.52 PID integral output -100.0%–100.0%
PID differential
P17.53
output
PID present
P17.54
proportional gain
PID present integral
P17.55
gain
PID present
P17.56
differential time
Peak value at
100Hz frequency
component
P17.57
(square-wave
orthogonal function
detected)
Peak value at
100Hz frequency
component
P17.58
(sine-wave
orthogonal function
detected)
P17.59–
Reserved
P17.63
Description
0–65535
0–65535
0.00–P00.03
0.00–P00.03
-100.0%–100.0%
-100.0%–100.0%
0.00–100.00
0.00–10.00s
0.00–10.00s
0.0–300.0V
Peak value of bus voltage fluctuation at
100Hz frequency component, which is
detected by using a square-wave orthogonal
function
0.0–300.0V
Peak value of bus voltage fluctuation at
100Hz frequency component, which is
detected by using a sine-wave orthogonal
function
0–65535
-239-
Function parameter list
Default
Modify
value
●
0
●
0
●
0.00Hz
●
0.00Hz
●
0.0%
●
0.0%
●
0.0%
●
0.00
●
0.00s
●
0.00s
●
0.0V
●
0.0V
●
0
