INVT Goodrive350A Series Operation Manual page 289

Goodrive350A series high-performance multifunction VFD
Function
Name
code
selection
Roll diameter value
P91.28
Tension taper
P91.29 coefficient for roll
diameter value 1
Roll diameter value
P91.30
Tension taper
P91.31 coefficient for roll
diameter value 2
Tension offset value
P91.32
at zero speed
Present roll
P91.33
diameter setting
P92—Customized tension control functions
Function
Name
code
Pre-drive speed
P92.00
gain
Pre-drive torque
P92.01
limit
Pre-drive torque
P92.02
limit setting
Zero bit conversion
P92.03
enabling
P92.04 Initial zero bit
P92.05 Final zero bit
Conversion time
P92.06 from initial zero bit
to final zero bit
Conversion time
P92.07
from final zero bit to
0: Inverse proportional curve
1: Multi-point curve
0.0–5000.0mm
1
0.0–50.0%
0.0–5000.0mm
2
0.0–50.0%
0.0–300.0%
0.0–5000.0mm
0.0–100.0%
0–2
0: Set based on P03.20, P03.21
1: Set based on P93.02
2: Set based on the set tension
0.0–200.0%
0–1
0: Disable
1: Enable
0.0–100.0%
0.0–100.0%
0.00–60.00s
0.00–60.00s
Description
Description
-284-
Function parameter list
Default Modify
○
200.0 mm
○
3.0%
○
500.0 mm
○
7.0%
○
0.0%
◎
0.0mm
Default Modify
○
100.0%
○
2
○
100.0%
◎
0
○
10.0%
○
50.0%
○
5.00s
○
5.00s
