INVT Goodrive350A Series Operation Manual page 232

Goodrive350A series high-performance multifunction VFD
Function
Name
code
P15.13 Sent PZD2
P15.14 Sent PZD3
P15.15 Sent PZD4
P15.16 Sent PZD5
P15.17 Sent PZD6
P15.18 Sent PZD7
P15.19 Sent PZD8
P15.20 Sent PZD9
P15.21 Sent PZD10
P15.22 Sent PZD11
P15.23 Sent PZD12
Description
14: High-order bit of position reference
(signed)
15: Low-order bit of position reference
(unsigned)
16: High-order bit of position feedback
(signed)
17: Low-order bit of position feedback
(unsigned)
18: Position feedback setting flag (position
feedback can be set only after this flag is set
to 1 and then to 0)
19: Function parameter mapping
(PZD2–PZD12 correspond to
P14.49–P14.59)
20–31: Reserved
0–31
0: Invalid
1: Running frequency (x100, Hz)
2: Set frequency (x100, Hz)
3: Bus voltage (x10, V)
4: Output voltage (x1, V)
5: Output current (x10, A)
6: Actual output torque (x10, %)
7: Actual output power (x10, %)
8: Rotation speed of running (x1, RPM)
9: Linear speed of running (x1, m/s)
10: Ramp reference frequency
11: Fault code
12: AI1 input (x100, V)
13: AI2 input (x100, V)
14: AI3 input (x100, V)
15: HDIA frequency value (x100, kHz)
16: Terminal input status
17: Terminal output status
18: PID reference (x100, %)
19: PID feedback (x100, %)
20: Motor rated torque
21: High-order bit of position reference
-227-
Function parameter list
Default
Modify
value
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
