Goodrive350A series high-performance multifunction VFD
Present
reference
channel
P00.09
A
B
A+B
A-B
Max(A,B)
Min(A,B)
Note: "/" indicates this multifunction terminal is invalid under present reference channel.
When setting the auxiliary frequency inside the VFD via multi-function terminal UP (10) and DOWN
(11), you can increase/decrease the frequency quickly by setting P08.45 (UP terminal frequency
incremental change rate) and P08.46 (DOWN terminal frequency decrement change rate).
UP terminal
function selection=10
DOWN terminal
function selection=11
Related parameter list:
Function
code
P00.03 Max. output frequency
Upper limit of running
P00.04
Lower limit of running
P00.05
Setting channel of A
P00.06
frequency command
P00.07 Setting channel of B
Multifunction
terminal function 13
Channel A switched
to channel B
B
A
/
/
/
/
F
Sx
Sy
Name
frequency
frequency
Multifunction
terminal function 14
Combination setting
switched to channel
A
/
/
A
A
A
A
UP terminal frequency incremental integral speed P08.45
DOWN terminal frequency decremental integral speed P08.46
Description
P00.04–400.00Hz
P00.05–P00.03
0.00Hz–P00.04
0: Keypad
1: AI1
2: AI2
-83-
Basic operation guidelines
Multifunction
terminal function 15
Combination setting
switched to channel
B
/
/
B
B
B
B
T
UP terminal state
T
DOWN terminal state
T
Default
50.00Hz
50.00Hz
0.00Hz
0
15
