Goodrive350A series high-performance multifunction VFD
Function
code
Enabling IF mode
P04.45
Current setting in
P04.46
IF mode for AM 2
Proportional
coefficient in IF
P04.47 mode for AM 2
proportional
coefficient
Integral coefficient
P04.48 in IF mode for AM
Starting frequency
point for switching
P04.49
off IF mode for AM
End frequency
point for switching
P04.50
off IF mode for AM
End frequency
point for switching
P04.51
off IF mode for AM
5.5.5 Torque control
The VFD supports torque control and speed control. Speed control aims to stabilize the speed to keep
the set speed consistent with the actual running speed, meanwhile, the max. load-carrying capacity is
restricted by the torque limit. Torque control aims to stabilize the torque to keep the set torque
consistent with the actual output torque, meanwhile, the output frequency is restricted by the upper
and lower limits.
Name
1
0: Disable
for AM 2 1: Enable
When IF control is adopted for AM 2, the
function code is used to set the output current.
The value is a percentage in relative to the
rated current of the motor.
Setting range: 0.0–200.0%
When IF control is adopted for AM 2, the
function code is used to set the proportional
coefficient of output current closed-loop control.
Setting range: 0–5000
When IF control is adopted for AM 2, the
function code is used to set the integral
coefficient of output current closed-loop control.
2
Setting range: 0–5000
0.00–P04.51
2
P04.44–P00.03
1
P04.49 – P00.03
2
Description
-66-
Basic operation guidelines
Default
0
120.0%
650
350
10.00Hz
25.00Hz
25.00Hz
