INVT Goodrive350A Series Operation Manual page 78

Goodrive350A series high-performance multifunction VFD
Function
code
Channel of running
P00.01
Motor parameter
P00.15
P02.00 Type of motor 1
P02.01 Rated power of AM 1
Rated frequency of
P02.02
P02.03 Rated speed of AM 1
P02.04 Rated voltage of AM 1 0–1200V
P02.05 Rated current of AM 1 0.8–6000.0A
Stator resistance of
P02.06
P02.07 Rotor resistance of AM 0.001–65.535Ω
Name
0: Keypad
1: Terminal
commands
2: Communication
0: No operation
1: Rotary autotuning 1.
Comprehensive motor parameter
autotuning. It is recommended to use
rotating autotuning when high control
accuracy is needed.
2: Static autotuning 1 (comprehensive
autotuning); static autotuning 1 is used in
cases where the motor cannot be
disconnected from load.
autotuning
3: Static autotuning 2 (partial autotuning);
when the present motor is motor 1, only
P02.06, P02.07 and P02.08 are autotuned;
when the present motor is motor 2, only
P12.06, P12.07 and P12.08 are autotuned.
4: Rotary autotuning 2. Similar to rotary
autotuning 1, but it is valid only for AMs.
5: Static autotuning 3 (partial autotuning),
valid only for AMs.
0: Asynchronous motor (AM)
1: Synchronous motor (SM)
0.1–3000.0kW
0.01Hz–P00.03 (Max. output frequency)
AM 1
1–60000rpm
0.001–65.535Ω
AM 1
Description
-73-
Basic operation guidelines
Default
0
0
0
Model
depended
50.00Hz
Model
depended
Model
depended
Model
depended
Model
depended
Model
