Replacing The Speaker; Figure 8-9 Removing The Speaker From The Fan/Speaker Bracket - Sun Microsystems Ultra 1 Creator Series Service Manual

Speaker
FIGURE 8-9
8.3.2

Replacing the Speaker

Caution – Use proper ESD grounding techniques when handling components. Wear
!
an antistatic wrist strap and use an ESD-protected mat. Store ESD-sensitive
components in antistatic bags before placing it on any surface.
1. Replace the fan/speaker bracket as follows (
a. Position the speaker in the fan/speaker bracket.
b. Insert the fan/speaker bracket into the chassis.
c. Verify the tabs are locked into the chassis to ensure proper replacement.
8-12 Ultra 1 Creator Series Service Manual • August 1996
Removing the Speaker from the Fan/Speaker Bracket
Fan/speaker bracket
):
FIGURE 8-10
