FIGURE 10-2
FIGURE 10-3
10.1.2
Replacing a System Board
Caution – Use proper ESD grounding techniques when handling components. Wear
!
an antistatic wrist strap and use an ESD-protected mat. Store ESD-sensitive
components in antistatic bags before placing it on any surface.
10-4
Ultra 1 Creator Series Service Manual • August 1996
Captive screw
Captive Screws on the Back Panel
Chassis
Sliding the System Board Out of the Chassis
Captive screw
Chassis
System board
