- Page 1 Ultra 2 Series to Sun ™ ™ ™ Ultra 60 System Upgrade ™ Guide A Sun Microsystems, Inc. Business 901 San Antonio Road Palo Alto, CA 94303 USA 650 960-1300 fax 650 969-9131 Part No.: 805-1767-10 Revision A, December 1997...
- Page 2 Sun, Sun Microsystems, le logo Sun, AnswerBook, SunDocs,Ultra, et Solaris sont des marques de fabrique ou des marques déposées, ou marques de service, de Sun Microsystems, Inc. aux Etats-Unis et dans d’autres pays. Toutes les marques SPARC sont utilisées sous licence et sont des marques de fabrique ou des marques déposées de SPARC International, Inc.
- Page 3 FCC radio frequency emission limits. Networking connections can be made using unshielded twisted-pair (UTP) cables. Modifications: Any modifications made to this device that are not approved by Sun Microsystems, Inc. may void the authority granted to the user by the FCC to operate this equipment.
- Page 4 This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Sun Ultra 2 Series to Sun Ultra 60 System Upgrade Guide • December 1997...
-
Page 5: Table Of Contents
Contents Preface vii Overview 1 Tools Required 1 Upgrade Kit 1 Safety Requirements 2 Symbols 3 System Precautions 4 Lithium Battery 4 Performing the Upgrade 5 Overview 5 Powering Off the System 6 Removing the Cover 8 Attaching the Antistatic Wrist Strap 10 Removing DIMMs 11 Removing a CD-ROM Drive 14 Replacing the Bracket into the Chassis 16... - Page 6 Sun Ultra 2 Series to Sun Ultra 60 System Upgrade Guide • December 1997...
-
Page 7: Preface
How This Book Is Organized Chapter 1 “Overview,” outlines the process to be followed in upgrading a Sun Ultra 1 or Ultra 1 Creator Series system to a Sun Ultra 60 System. Chapter 2 “Performing the Upgrade,” describes how to remove components from an Ultra 1 Series system to be transferred to an Ultra 60 System. - Page 8 The docs.sun.com Web site enables you to access Sun technical documentation online. You can browse the docs.sun.com archive or search for a specific book title or subject. The URL is http://docs.sun.com/. viii Sun Ultra 2 Series to Sun Ultra 60 System Upgrade Guide • December 1997...
- Page 9 What Typographic Changes Mean The following table describes the typographic changes used in this book. Typographic Conventions TABLE P-1 Typeface or Symbol Meaning Example The names of commands, files, Edit your .login file. AaBbCc123 and directories; on-screen Use ls -a to list all files. computer output machine_name% You have mail.
- Page 10 Sun Ultra 2 Series to Sun Ultra 60 System Upgrade Guide • December 1997...
-
Page 11: Overview
Electrostatic discharge kit, part number 560-1302, so you can safely handle parts that are sensitive to damage by static electricity. Sun Ultra 2 Series to Sun Ultra 60 System Upgrade Guide, (part number 805-1767). -
Page 12: Safety Requirements
Place all components removed from the system onto the ESD mat. Printed circuit board Handle a printed circuit board by the edges only. Store printed- circuit boards in antistatic bags. Sun Ultra 2 Series to Sun Ultra 60 System Upgrade Guide • December 1997... -
Page 13: Symbols
Safety Precautions (Continued) TABLE 1-1 Item Problem Precaution Cover System damage Replace the cover after servicing the system. and overheating SBus slot filler panels System damage Install filler panels in all unused SBus slots. Openings on the back and overheating panel reduce the cooling capability of the system and allow EMI emissions that exceed FCC compliance limits. -
Page 14: System Precautions
Batteries are not customer replaceable parts. They may explode if mistreated. Do not dispose of the battery in fire. Do not disassemble it or attempt to recharge it. Sun Ultra 2 Series to Sun Ultra 60 System Upgrade Guide • December 1997... -
Page 15: Performing The Upgrade
Ultra 60 Installation Guide. Note – SBus cards are not supported by the Ultra 60 system. d. Connect the monitor, keyboard, and mouse to the Ultra 60 system as shown in the Ultra 60 Installation Guide. 3. Follow the instructions in the RMA information package about packing and returning the Ultra 2 Series enclosure and those components not moved to the Ultra 60. -
Page 16: Powering Off The System
Caution – Failure to shut down the operating system can result in loss of data. 4. Turn off the power to the monitor. 5. Turn off all attached external devices. Sun Ultra 2 Series to Sun Ultra 60 System Upgrade Guide • December 1997... - Page 17 6. Place the power on/standby switch to standby ( ) ( FIGURE 2-1 7. Verify the following: a. Front panel LED is off. b. System fans are disabled. Power on/standby switch Rear View of an Ultra 2 System FIGURE 2-1 8.
-
Page 18: Removing The Cover
FIGURE 2-3 b. When the cover clears the back panel, move the cover away from the front panel to free it from the chassis and set aside. Sun Ultra 2 Series to Sun Ultra 60 System Upgrade Guide • December 1997... - Page 19 Top cover tab (2) Cover Removing the Cover FIGURE 2-3 Chapter 2 Performing the Upgrade...
-
Page 20: Attaching The Antistatic Wrist Strap
Wrist strap Copper end Attaching the Antistatic Wrist Strap FIGURE 2-4 When used properly, a wrist strap keeps static electricity from building up on your hands. Sun Ultra 2 Series to Sun Ultra 60 System Upgrade Guide • December 1997... -
Page 21: Removing Dimms
Removing DIMMs Caution – A DIMM is made of delicate electronic components that are extremely sensitive to static electricity. Handle a DIMM only by the edges. Do not touch the components on the DIMM or any metal parts. Wear an antistatic wrist strap before unpacking and while handling a DIMM. - Page 22 3. Lift the right side of the shroud and swing it toward the left side of the system case. The DIMMs are now accessible for removal. Shroud Shroud covering DIMMs. FIGURE 2-7 Sun Ultra 2 Series to Sun Ultra 60 System Upgrade Guide • December 1997...
- Page 23 See the Sun Ultra 60 Installation Guide for instructions. Note – DIMMs in a Ultra 60 must be installed in groups of four. Each pair of DIMMs installed in a given bank of four must be of the same speed and capacity.
-
Page 24: Removing A Cd-Rom Drive
From the diskette drive (P2) if any. 7. Disconnect the diskette cable from the diskette drive (if any). 8. Place the bracket on the antistatic mat. Sun Ultra 2 Series to Sun Ultra 60 System Upgrade Guide • December 1997... - Page 25 Ultra 60 System. 10. Remove the CD-ROM drive, and place it aside on an antistatic surface. 11. Install the CD-ROM drive in the Ultra 60 System. Refer to the Ultra 60 Installation Guide for installation instructions. Chapter 2...
-
Page 26: Replacing The Bracket Into The Chassis
5. Connect the DC harness to the peripheral power cable at P1. 6. Replace the DC harness to the clip located on the drive bracket. 7. Replace the screws securing the drive bracket to the chassis. Sun Ultra 2 Series to Sun Ultra 60 System Upgrade Guide • December 1997... -
Page 27: Replacing The Cover
Replacing the Cover 1. Hold the cover at a 30-degree angle to the system unit. 2. Position the cover lip to the chassis lip. 3. Lower the cover onto the system unit so that the rear of the cover is supported by the chassis back panel ( FIGURE 2-11 4. - Page 28 Sun Ultra 2 Series to Sun Ultra 60 System Upgrade Guide • December 1997...
