DSIMM
Disk fan
Disk drive
Speaker
FIGURE 1-4
1-8
Ultra 1 Creator Series Service Manual • August 1996
SBus card
Chassis
SBus card slot (2)
System Unit with Cover Removed
Cover
System board
Power supply
CD-ROM drive
(may be exchanged with either
4-mm tape drive or 8-mm tape drive)
Diskette
drive
