REVO C 2PH from 60A to 800A - 690V
6

Technical Specifications

6.1 General features

Operative voltage:
Cover and Socket material:
Utilization Category:
IP Code:
Method of Connecting:
Auxiliary voltage:
Order code RC2_ _ _ -_1 = line voltage 100/120V transformer range 90:135V (8 VA Max)
Order code RC2_ _ _ -_2 = line voltage 200/208/220/230/240V transformer range 180:265V (8 VA Max)
Order code RC2_ _ _ -_3 = line voltage 277 transformer range 238:330V (8 VA Max)
Order code RC2_ _ _ -_5 = line voltage 380/400/415/440/480V transformer range 342:528V (8 VA Max)
Order code RC2_ _ _ -_6 = line voltage 600V transformer range 540:759V (8 VA Max)
Order code RC2_ _ _ -_7 = line voltage 690V transformer range 540:759V (8 VA Max)
Relay output for Heater Break Alarm
(only with HB option):

6.2 Input features

Digital Input:
Volt Analogic input:
Current Analogic input:
Potentiometer:
Logic input SSR (Fast Enable):

6.3 Output features (power device)

Repetitive peak
Nominal
reverse voltage
Current Voltage
range (Ue)
(A) (V) (480V)
60A 24÷690 1600
90A 24÷690 1600
120A 24÷690 1600
150A 24÷690 1600
180A 24÷690 1600
210A 24÷690 1600
300A 24÷690 1600
400A 24÷690 1600
450A 24÷690 1600
500A 24÷690 1600
600A 24÷690 1600
700A 24÷690 1600
800A 24÷690 1600
4 ÷ 30Vdc 5mA Max (ON >4Vdc OFF <1Vdc) 0,5Hz max
0 ÷ 10Vdc impedance 15 kΩ
0 ÷ 20mA impedance 100 Ω
4 ÷ 20mA impedance 100 Ω
10 kΩ min.
4 ÷ 30Vdc 5mA Max (ON >4Vdc OFF <1Vdc)
duty cycle min. 100 ms max 3Hz
Latching Max peak
one cycle
current
(Uimp)
(10msec.)
(690V) (mAeff)
1800 600
1800 600
1800 600
1800 400
1800 400
1800 400
1800 400
1800 200
1800 200
1800 200
1800 200
1800 200
1800 200
690V +5% max -10% min
PolymericV2
AC-51 AC-55b
20
Load in Delta, Load in Star
0.5A a 125Vac
FUSE I2T value
Leakage
Suggested A2s
current
(at690V)
(mAeff)
tp=10msec
(A)
1900 15 16940
1900 15 16940
1900 15 16940
1900 15 27500
1900 15 48400
1900 15 84700
1900 15 79750
7820 15 236500
7820 15 338800
7820 15 338800
7820 15 462000
7820 15 462000
7820 15 387200
18
User's manual
Power loss Isolation
Frequency
Thyristor +
Voltage
range
Fuse
(Hz) I=Inom (W)
47÷70 205 3000
47÷70 290 3000
47÷70 398 3000
47÷70 409 3000
47÷70 486 3000
47÷70 598 3000
47÷70 903 3000
47÷70 1092 3000
47÷70 1259 3000
47÷70 1407 3000
47÷70 1528 3000
47÷70 1753 3000
47÷70 2281 3000
(Ui)
Vac
