REVO RT
from 35A to 90A
5

Technical Specifications

5.1 General features

Cover and Socket material:
Utilization Category:
IP Code:
Method of Connecting:
Auxiliary voltage:
Relay output for Heater Break Alarm
(only with HB option)

5.2 Input and Output features (power device)

Nominal
Current Voltage
range (Ue)
(A) (V) (480V)
30 24÷600
50 24÷600
75 24÷600
90 24÷600

5.3 Input features (electronic control board)

configurable via software
Input n°: 3
Resolution 16Bit
Thermocouple
Type: K, S, R, J, T, E, N, B with automatic joint compensation
Tolerance +/- 0,2% FS
Cold junction accuracy +/- 0,1 °C/°C
V/mA
Type: 0-1V, 0-5V, 0-10V, 0-20mA, 4-20mA, 0-60mV
Impedence: 0-10 V: > 110 KΩ
0-20 mA: < 5 Ω
0-60 mV: > 1 MΩ

5.4 Output features (electronic control board)

Relay
Function: Cooling, temperature alarms, system alarms, system signals
DO 1,2,3: 230Vac / 1A resistive load
AL4: 230Vac / 1A resistive load
AL5: 24V / 1A
Polymeric V2
AC-51 AC-55b AC-56A
20
Load in Delta, Load in Star
24Vdc 1A
0.5A a 24Vac/dc
Repetitive peak
Latching
reverse voltage
current
(Uimp)
(600V) (mAeff)
1600 600 520
1600 600 1500
1600 600 1900
1600 600 1900
FUSE I2T
value
Max peak Leakage
Suggested
one cycle current
A2s
(at500V)
(10 msec.) (mAeff)
(A) 10msec
15 546 47÷70
15 1750 47÷70
15 4305 47÷70
15 4305 47÷70
16
User's manual
Power loss
Frequency
Thyristor +
range
Fuse
tp= (Hz) I =Inom (W)
36 3000
54 3000
102 3000
145 3000
Isolation
Voltage
(Ui)
(Vac)
3000
3000
3000
3000
