Technical Specifications; General Features; Input Features; Output Features (Power Device) - CD Automation REVEX 1PH 280A User Manual

REVEX
1PH 280A
6

Technical Specifications

6.1 General features

Cover and Socket material:
Utilization Category:
IP Code:
Method of Connecting:
Auxiliary voltage
Order Code RX1___-_4:
Relay output for Heater Break Alarm
(only with HB option)

6.2 Input features

Digital Input:
Volt Analogic input:
Current Analogic input:
Potentiometer:
Logic input SSR (Fast Enable):

6.3 Output features (power device)

Nominal
Current Voltage
range (Ue)
(A) (V) (480V)
280 24÷600

6.4 Fan Specification

Supply: 24Vdc

6.5 Environmental installation conditions

Ambient temperature
Storage temperature
Installation place
Altitude
Humidity
Pollution Level
Repetitive peak
Latching
reverse voltage
current
(Uimp)
(600V) (mAeff)
1200 1600 300
PolymericV2
AC-51 AC-55b
20
Single Phase Load
24Vdc (1A)
0.5A a 125VAC
4 ÷ 30Vdc 5mA Max (ON >4Vdc OFF <1Vdc) 5Hz max
0 ÷ 10Vdc impedance 15 kΩ
4 ÷ 20mA impedance 100 Ω
10 kΩ min.
4 ÷ 30Vdc 5mA Max (ON >4Vdc OFF <1Vdc)
3Hz Max duty cycle min. 100 ms
FUSE I2T
value
Max peak Leakage
Suggested
one cycle current
(at500V)
(10 msec.) (mAeff)
(A) 10msec
5000 15 125000
Power 7W (1 Fan)
0-40°C (32-104°F) at nominal current. Over 40°C-104°F use
the derating curve (max 50°C).
-25°C to 70°C -13°F to 158°F
Don't install at direct sun light, where there are conductive
dust, corrosive gas, vibration or water and also in salty
environmental.
Up to 1000 meter over sea level. For higher altitude reduce
the nominal current of 2% for each 100m over 1000m
From 5 to 95% without condense and ice
Up to 2nd Level ref. IEC 60947-1 6.1.3.2
16
User's manual
Power loss
Frequency
Thyristor +
range
A2s Fuse
tp= (Hz) I =Inom (W)
47÷70 350
Isolation
Voltage
(Ui)
Vac
2500
