Schematic (Size S13-S14) - CD Automation REVO C 2PH 690V User Manual

REVO C 2PH from 60A to 800A - 690V

8.7 Schematic (Size S13-S14)

(Size S13: 120-210A 690V / S14: 300-700A 690V)
Caution: this procedure must be performed only by qualified persons.
L3 L2 L1
Branch circuit
protection
Fuse
1A Max
L3 L2 L1
T3 T2 T1
TO LOAD
M1
15 16
18 20
Power FAN
supply power
Digital
+10Vdc
Input 2 Input 1
supply
9 10 13 5
+10V GND COM I DI 2
M1
Micro USB
Microprocessor
USB
& Wi-Fi
Digital
Analog
Input 1
6 12 11
+ -
DI 1
30
User's manual
Option
Ethernet
M2
+24V GND
4
+24Vdc Retransmit
power input output
Analog
Relay output
Input 2
4 3 1 2
+
NC NO C
Profibus
M5
A + B-
Second
comm. port
RS485
7 8
A + B-
