REVO C 2PH from 60A to 800A - 690V
9.4.4 Hardware Menu
This section describes each item on the hardware menu. Use this menu to configure how the inputs and
outputs are used in the application. The password to access this menu is 5.
Parameter Name
Analog In 1 Choose the type of signal to be measured by
analog input 1
Parameter Name
Analog In 2
Choose the type of signal to be measured by
analog input 2
Parameter Name
An2 Funct
Choose how the signal measured by analog input
2 is used
Description
Option
0-10V
0 to 10 Vdc or 10,000Ω
4-20mA
4 to 20 mAdc
0-20mA
0 to 20 mAdc
DEFAULT: 0-10V
Description
Option
0-10V
0 to 10 Vdc or 10,000Ω
4-20mA
4 to 20 mAdc
0-20mA
0 to 20 mAdc
DEFAULT: 0-10V
Description
Option
Feedback
External feed-back
Set Point
Power Demand set point
DEFAULT: Feedback
Description
Description
Description
46
User's manual
Modbus
Default
Address
1 44
Value
1
2
3
1
Modbus
Default
Address
1 105
Value
1
2
3
1
Modbus
Default
Address
1 116
Value
1
2
1
Par.
Type
Read
Write
Par.
Type
Read
Write
Par.
Type
Read
Write
