CD Automation REVO C 2PH 690V User Manual page 43

REVO C 2PH from 60A to 800A - 690V
9.4.2 Setup Menu
This section describes each item on the setup menu. Use this menu to configure the power controller for the
load. The password to access this menu is 2.
Parameter Name
Set the percentage by which the set point is
Out Scale
scaled. For example, if a 0 to 10V analog input
providing the set point is 5V and output scaling
is 80% then the effective set point is 40%
Parameter Name
Nom Line V
Set the nominal value for the line
voltage input
Nominal I
Set the nominal load current
SP select
Choose the source for the remote set
point
Description
100
80
60
40
20
0
0 20 40 60
Input
Description
Option Value
Analog In 1
Analog In 2
80 100
Default
220V
Maximum
current
0
1
43
User's manual
Modbus
Range Unit
Address
0 to 100.0 %
Modbus
Range Unit
Address
0 to 1023 V
0 to
A
6000,0
Par.
Type
Read
16
Write
Par.
Type
Read
37
Write
Read
38
Write
Read
61
Write
