REVO C 2PH from 60A to 800A - 690V

8.6 Control Terminals

Warning: Before connecting or disconnecting the unit check that power and control cables
are isolated from voltage sources.
Terminal Block M1
Terminal Description
1 NO - Normally Open contact alarm relay output (HB)
2 C - Common contact alarm relay output
3 NC - Normally Close contact alarm relay output (HB)
4 + Analog Input 2 (0-10Vdc/4-20mA Reference/ext.feedback)
5 DI 2 - Enable Digital Input
6 DI 1 - Configurable Input
7 RS485 A+
8 RS485 B-
9 Output +10Vdc stabilized 1 mA MAX
10 0V GND
Terminal Description
11 - Analog Input 1 (0-10Vdc/4-20mA Analog Setpoint)
12 + Analog Input 1 (0-10Vdc/4-20mA Analog Setpoint)
13 COM I - Common Digital Input
14 Not Connected
15 Fan supply (230V Standard – 115 Option - for DC Fan Option +24Vdc)
16 Fan supply (230V Standard – 115 Option - for DC Fan Option -24Vdc)
17 Not Connected
18 Aux – Voltage Supply for electronic boards and synchronization (See order code for the Value)
19 Not Connected
20 Aux – Voltage Supply for electronic boards and synchronization (See order code for the Value)
Terminal Block M2
Terminal Description
1 24V Out Max 5mA
2 Slave Output
3 Retransmission Output
4 0V GND
