REVO C 2PH from 60A to 800A - 690V
Parameter Name
Choose for which conditions the digital output
Alm Out Fn
indicates alarm. The output always indicate an
alarm when the heat sink is over temperature. The
digital output is energized for normal operating
condition and de-energized when the power
controller is off or when there is an alarm.
Note!: The power controller monitors for heater
break or short circuit condition only when included
in the option selected for Alarm Output Function
Option
Heater Break
Short Circuit
Therm
Communication
DEFAULT
Alarm Bitwise is allowed
Parameter Name
Retransmit
Choose which parameter is retransmitted by the
analog output
DEFAULT: Power
Description
Heater Break
Short circuit
SCR is over temperature
Communication watchdog error
Description
Option
Set Point
Set point
Volts Out
RMS voltage output
Power
Average output power
Current
RMS current output
None
Do not retransmit value
Description
Default
Description
48
User's manual
Modbus
Default
Address
1 34
Modbus
Address
12 68
Value
15
10
12
11
0
12
Par.
Type
Read
Write
Bit
0
1
3
4
None
Par.
Type
Read
Write
