Parameter List - CD Automation REVO C 2PH 690V User Manual

REVO C 2PH from 60A to 800A - 690V

9.4 Parameter list

This chapter describes the parameter on the menus accessed via the control panel and Configurator software.
To learn how to access the menus described below see "Menu navigation" chapter.
Menu Listing
The table below lists the parameters found on each menu. See the following pages for descriptions and other
details of each parameter.
Operator Setup
Set Point Out Scale
Volts Out Nom Line V
Current Nominal I
Power SP Select
Volts In
Frequency
Pwr Factor
Load Ω
Out Scale
Nom Line V
Nominal I
Read/write Read only
Advanced Setup
Firing Type
Min Cycle Analog in 2
Start Ramp
Delay
Cycle Time
Feedback
Pb Power Retransmit
Ti Power
HB Sense
HB Delay
Logging
Log Period
41
Hardware Communication
Analog in 1 Port 1 Baud
Port 1 Addr
An2 Funct Port 2 Baud
DI1 Functn Watchdog
DI2 Functn WD Reset
Alm Out Fn Wi-Fi Addr
Field Name
Rtx Scale Unit Name
Rtx Type Port 2 Addr
Start Disp Port 2
Wi-Fi
User's manual
Monitoring
Dig in 1
Dig in 2
Enable
SP Source
Analog In1
Analog In2
SW Ver
SW Rel
Unit Type
Max Voltage
Max Current
Aux Voltage
Serial No.
SCR Temp
