REVO C 2PH from 60A to 800A - 690V
Size S13: 120-210A 690V / S14: 300-700A 690V
Caution: this procedure must be performed
only by qualified persons.
Indicative connection diagrams. Refer to local
regulations for proper system protection.
L3 L2
Branch Circuit
Protection
L3 L2
T3 T2
TO LOAD
NOTE:
1 The user installation must be protecting by electromagnetic circuit breaker or by fuse isolator.
The Fuse must be branch circuit protection. For UL any listed UL branch circuit fuse would be acceptable
as an external fuse, following national electric code guide for resistive heating of 125% load current rating
to protect external wires.
2 On phase L2 fuse not available for size 600-700A
3 For SSR input connection follow next page schematic.
4 IMPORTANT! Starting Strategy (Enable):
1: Feed the unit with L1-L2-L3 power voltage supply
2: Feed the auxiliary supply
3: Close the Enable contact to start with the regulation.
L1
Fuse
1A Max
M1
AUX AUX
L1 18 20
T1
9 10 13
M1
M5
MICRO
Fan Supply
USB 2.0
230 Vac Standard
115 Vac Option
24 Vdc Option
See Order Code
15 16
Analog Input 1
5 6 12 11
4
3
9
10
Analog Inp.1
Analog SetPoint
31
User's manual
Option
Second
Ethernet
Serial RS485
-
+
24Vdc input
M2
+24V
GND
1 2 3 4
Analog Input 2
4 11 3 1 2
NC NO C
Function
Thermal
SC/HB
10 9
Analog Inp.2
Reference
Ext.FeedBack
Profibus
8 7
A+
B-
