REVO C 2PH from 60A to 800A - 690V

8.10 Connection Diagram for 3 phases (control on 2 phases)

(Size S13: 120-210A 690V / S14:300-700A 690V)
Caution: this procedure must be performed only by qualified persons.
Relay
Thermal or
SC/HB
Analog Inp.2
0-10VDC /4-20mA
Reference
Ext.FeedBack
Analog Inp.1
0-10VDC /4-20mA
ANALOG SET POINT
Fan Power Supply
See Order Code for the value
AUX Voltage Supply
See Order Code for the value
X = not connected
1 The user installation must be protecting by electromagnetic circuit breaker or by fuse isolator.
*
The Fuse must be branch circuit protection. For UL any listed UL branch circuit fuse would be acceptable
as an external fuse, following national electric code guide for resistive heating of 125% load current rating to
protect external wires.
M2
+24V
SLAVE OUT
RETRANS. OUT
L1
T1
Note: Aux Voltage and Load Voltage
must be synchronized
37
User's manual
L3
T3
