Displaying The Incoming List - Icom IC-F5400DP Series Operating Manual

8
BIIS 1200 SYSTEM OPERATION

Displaying the Incoming list

The transceiver saves a log of the received Individual
calls, Group calls, Status messages, Messages, and
Emergency calls in the memory�
Up to 10 Message/Status/Emegency or 5 Voice calls
can be saved in the log, and the oldest call record is
erased when an 11th (Message/Status/Emegency)
or 6th (Voice) call is received� However, once the
transceiver is turned OFF, all of the records are
erased�
<Menu operation>
Portable: For the Ten-key and the Simple key types
Mobile: For the LCD types
(Menu > Signaling/Call > Incoming)
1� Push [Menu] to display the Menu screen�
2� Push [Left] or [Right] to select "Signaling/Call,"
then push [OK]�
3� Push [Up] or [Down] to select "Incoming," then
push [OK]�
4� Push [Up] or [Down] to select "Voice" or
"Message/Status," then push [OK]�
• Voice:
• Message/Status: The received Status message
The received Individual call
and Group call logs are saved�
and Message logs are saved�
5� When "Voice" is selected in step 4, the "Voice"
screen is displayed�
• The calling station name (or ID) is displayed�
TIP: When the "Voice" screen is displayed, skip
step 6 and go to step 7�
When "Message/Status" is selected in step 4, the
"Message/Status" screen is displayed�
• The calling station name (or ID) is displayed�
6� Push [Up] or [Down] to select the log, then push
[OK]�
• The message content is displayed�
7� Hold down [Back] for 1 second to return to the
standby screen�
8-14
