2
PANEL DESCRIPTION
Assignable Software key functions
D For keys and keypads (Continued)
Disable
Set to disable the key
NOTE: This key function is assignable to only
[Ext Emer]
Null
No function
Menu
Push to display the "Menu" screen
L Depending on the presetting, you may be able to make
various calls, select various functions and adjust the
transceiver settings in the Menu screen
L In the Menu screen, you cannot use the assigned key
functions
Home
In the Analog mode
z Push to reset the destination station code to the
default, if it has been manually changed
z While in the Audible mode, push to return to the
Inaudible mode and automatically send a reset
code or Clear Down signal
In the Digital mode
z Push to reset the destination Unit ID and call type to
the default, if they have been manually changed
z Push to cancel the Talk Back function, if it is
activated
z While in the Audible mode, push to return to the
Inaudible mode and automatically send a reset
code or Clear Down signal
z While in the Selection mode (Message, Status
Message, and so on), hold down for 1 second to
return to the Standby mode
• The transceiver resets the destination Unit ID, call type
and Talk Back function to the default
Shift
1 Push to enter the Shift mode
• A user can use a Software key's secondary function in
the Shift mode
2 Push this key again to return to the Normal mode
Category: Channel/Scan (Voting)
CH Up, CH Down
z Push to select an operating channel
z A fter pushing specific keys, push to select an
option, setting, and so on
Priority A, Priority B
Push to select the Priority A or Priority B channel
Priority A (Rewrite), Priority B (Rewrite)
z Push to select the Priority A or Priority B channel
z Hold down for 1 second to assign the operating
channel to the Priority A or Priority B channel
Zone Up, Zone Down
Push to select an operating zone
Zone Select
Push to display the "Zone Select" screen Then, push
[Up] or [Down] to select a zone
TIP: What is a "Zone"?
Certain channels are grouped together and assigned
to a Zone according to their intended use
For example, Analog channels 'Station 1' and
'Station 2' are assigned to an "Analog" Zone, and
Digital channels 'Station 3' and 'Station 4' are
assigned to a "Digital" Zone
Scan Start/Stop
z Push to start or cancel a Scan
L When a scan started with the Power ON Scan or Auto
Scan function, pushing this key pauses the scan The
paused scan resumes after the preset time period has
passed
z Hold down for 1 second to display the "Scan List"
screen Then push [Up] or [Down] to select a list
NOTE: When Mode Dependent Scan is ON, a
user may not be able to display the Scan list,
depending on the presetting
2-17
