OPERATING GUIDE
OPERATING GUIDE FOR
IC-F5062D/F6062D
BIIS 1200/dPMR OPERATION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IC-F6062D and is the answer not in the manual?

Questions and answers

Related Manuals for Icom IC-F6062D

Summary of Contents for Icom IC-F6062D

  • Page 1 OPERATING GUIDE OPERATING GUIDE FOR IC-F5062D/F6062D BIIS 1200/dPMR OPERATION...
  • Page 2 • IC-F6062D uhf d pmr mobile transceiver Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incor- porated (Japan) in Japan, the United States, the United Kingdom, Germany, France, Spain, Russia and/or other countries.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS IMPORTANT ................i 3 dPMR OPERATION ..........13–27 ■ dPMR operation ............13 TABLE OF CONTENTS ............ii ■ dPMR display .............13 1 PREPARATION............1–2 ■ Receiving a call ............13 ■ Programmable function keys ........1 ■ Transmitting a call ............18 ■...

  • Page 4: Preparation

    The following functions can be assigned to [UP], [DOWN], [P0], [P1], [P2], [P3] and [P4] programmable function keys. The following key functions are required for dPMR operation. Consult your Icom dealer or system operator for details con- dPMR BUTTON cerning your transceiver’s programming.

  • Page 5: Preparation

    PREPARATION D For BIIS 1200 and dPMR operations D Additional key functions The following key functions are useful for both BIIS 1200 and • For BIIS 1200 and dPMR operations dPMR operations. The following key functions are recommended for both BIIS 1200 and dPMR operations, and function as described below.

  • Page 6: Biis 1200 Operation

    BIIS 1200 OPERATION ■ BIIS 1200 operation ■ Receiving a call D Receiving an Individual call The Binary Interchange of Information and Signalling (BIIS) 1200 standard is the best choice to add a data service to an q When an Individual call is received: existing system.

  • Page 7: D Receiving A Group Call

    BIIS 1200 OPERATION D Receiving a Group call D Receiving an Emergency call q When a Group call is received: q When an Emergency call is received: • Rings sound. • Rings sound. • “Emergency” and the calling station’s ID (or name) blink. •...

  • Page 8: D Receiving A Status Message

    BIIS 1200 OPERATION D Receiving a status message D Receiving an SDM q When a status message is received: q When an SDM is received: • Rings sound. • Rings sound. • The calling station’s ID (or name) and the status message blink. •...
  • Page 9 BIIS 1200 OPERATION D Displaying a received call record D Displaying a received message — Queue channel mode The transceiver memorizes up to 6 received messages. When The transceiver memorizes up to 3 calling station’s IDs. When the 7th message is received, the oldest message will be re- the 4th call is received, the oldest call record will be removed, moved, and the last received message will be added.

  • Page 10: Transmitting A Call

    BIIS 1200 OPERATION ■ Transmitting a call D Transmitting an Individual or Group call NOTE: If you want to make a call to the pre-programmed D General ID, skip step q and w, then directly go to step e. • Editing an ID q Push [BIIS Button] to enter the call code memory mode.
  • Page 11 BIIS 1200 OPERATION D Transmitting a status message q Push [BIIS Button] to enter the call code memory mode. You can send a pre-programmed status message to an indi- • “ ” appears. vidual station or to group stations. • The pre-programmed ID is displayed. There are 24 status messages that can be sent, and Status w Push [CH Up] or [CH Down] to select a desired Individual 22 and 24 messages have designated meanings.

  • Page 12: D Transmitting An Sdm

    BIIS 1200 OPERATION D Transmitting an SDM D Direct message input You can send a pre-programmed SDM to an individual station While displaying an SDM, you can edit or change the mes- or to group stations. sage using the optional HM-152T hand microphone The transceiver has 8 memories to store messages.
  • Page 13 BIIS 1200 OPERATION D Transmitting an Emergency call • Usable characters If an MSK channel is used as the Emergency channel, the transceiver can access the BIIS emergency mode. Characters If your transceiver is programmed for Silent operation, you ! ? ' " , ; : _ ( ) < > [ ] can transmit Emergency calls without the beep sounding or 1 (space) # * / + - = &...

  • Page 14: Position Data Transmission

    BIIS 1200 OPERATION ■ Position data transmission ■ Stun function When a GPS receiver is connected to the transceiver, the If a call is received with a specified ID, set as the killer ID, the position data (longitude and latitude) can be automatically stun function is activated and the transceiver is disabled.

  • Page 15: Horn Output

    BIIS 1200 OPERATION ■ Horn output ■ Printer connection When a horn is connected to the D-Sub 25-pin connector of When a printer is connected to the D-sub 25-pin connector of the transceiver, the Automatic Honking function is usable, de- the transceiver, received SDM and the calling station’s ID can pending on the pre-programmed settings.

  • Page 16: Dpmr Operation

    ■ dPMR operation ■ Receiving a call D Receiving an Individual call The IC-F5062D and IC-F6062D provide digital Private Mobile Radio (dPMR) operation that meets the 6.25 kHz bandwidth q When an Individual call is received: requirements for narrow band operation. This increases ef- •...

  • Page 17: D Receiving A Group Call

    dPMR OPERATION D Receiving a Group call D Receiving a status message q When a Group call is received: q When a status message is received: • Rings sound. • Rings sound. • “ ” appears and the mute is released. •...
  • Page 18 dPMR OPERATION D Receiving an SDM D Receiving a Stun, Kill or Revive call q When an SDM is received: If an Individual call with a Stun or Kill command is received • Rings sound. from a specified station, the transceiver will display “SORRY,” •...
  • Page 19 dPMR OPERATION D Receiving an Ambience Listening call D Talk back function If an Individual call with an Ambience Listening command is The Talk Back function allows you to select the same call received from a specified station, the transceiver will auto- mode (Analog or Digital) as the received call.
  • Page 20 dPMR OPERATION D Displaying a received call log entry Depending on the pre-programmed setting, the transceiver NOTE: Depending on the pre-programmed settings, push- ing [Call] while displaying a call log entry makes a Voice stores up to 10 call log entries. Individual Voice, Status and SDM call log entries are stored.

  • Page 21: Transmitting A Call

    dPMR OPERATION ■ Transmitting a call • When no acknowledgement is received dPMR operation allows you to make a call to a specific sta- tion (Individual call) or to a particular group (Talkgroup call). After making a call, the transceiver waits for an acknowledge- ment for the pre-programmed time period.
  • Page 22 dPMR OPERATION D Transmitting a Voice Call D Transmitting a Status Polling Call NOTE: If you want to make a call to the pre-programmed The transceiver can send a signal that causes the target sta- ID, skip step q and w, and directly go to step e. tion to automatically transmit its current status.
  • Page 23 dPMR OPERATION D Transmitting a status message You can send a pre-programmed status message to an indi- y Push [Call] to transmit the status message to the selected vidual station or to group stations. station or talkgroup. There are 32 status messages that can be sent. •...
  • Page 24 dPMR OPERATION D Transmitting an SDM You can send a pre-programmed SDM to an individual station u Push [Call] to transmit the SDM to the selected station or or to group stations. talkgroup. The transceiver has 10 memories to store messages. •...
  • Page 25 dPMR OPERATION D Direct message input • Usable characters While displaying an SDM, you can edit or change the mes- sage using the optional HM-152T hand microphone Characters ! ? ' " , ; : _ ( ) < > [ ] q Push [dPMR Button] twice to enter the application selec- 1 (space) # * / + - = &...
  • Page 26 dPMR OPERATION D Transmitting an Emergency call If a digital channel is used as the Emergency channel, the r After the Emergency call cycles have ended, the trans- transceiver can access the dPMR emergency mode. ceiver automatically returns to the stand-by mode. If your transceiver is programmed for Silent operation, you •...

  • Page 27: Transmitting A Command

    dPMR OPERATION ■ Transmitting a command D Transmitting a Stun Call The following Individual calls allow you to send special com- mands. These calls will function if you are designated as a A Stun call allows you to send a command that will stun the specific station.
  • Page 28 dPMR OPERATION D Transmitting a Kill Call D Transmitting a Revive Call A Kill call allows you to send a command that will disable the A Revive call allows you to send a command that will revive target station. the (stunned) station. q Push [dPMR Button] to enter the ID selection mode.

  • Page 29: Position Data Transmission

    dPMR OPERATION ■ Position data transmission ■ Status message transmission When a GPS receiver is connected to the transceiver, the Status messages can be automatically transmitted: position data (longitude and latitude) can be automatically • When the transceiver is turned ON or OFF transmitted.

  • Page 30: Horn Output

    dPMR OPERATION ■ Horn output ■ Printer connection When a horn is connected to the D-Sub 25-pin connector of When a printer is connected to the D-sub 25-pin connector of the transceiver, the Automatic Honking function is usable, de- the transceiver, received SDM and the calling station’s ID can pending on the pre-programmed settings.
  • Page 31 MEMO...
  • Page 32 A-6841-2EU 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan © 2010 Icom Inc.
