Required Tools

Clearances

Cutout Dimensions

Publication 2711PC-UM001A-EN-P - March 2009
These tools are required for panel installation:
• Panel cutout tools
• Small, slotted screwdriver
• Torque wrench (lb•in) for tightening the mounting clips on the
1000 terminal
Allow adequate clearance around the terminal, inside the enclosure,
for adequate ventilation. Consider heat produced by other devices in
the enclosure. The ambient temperature around the terminals must be
between 0...55 °C (32...131 ºF).
Clearance Area 400 and 600 Terminals
Top 51 mm (2 in.)
Bottom 102 mm (4 in.)
(1) 25 mm (1 in.)
Side
Back None
(1)
Minimum side clearance for insertion of memory card and cable wiring is 102 mm (4 in.).
Use the full size template shipped with your terminal to mark the
cutout dimensions.
Terminal Type
400 Keypad, or Keypad and Touch
600 Touch
1000 Touch
Installing the Terminal Chapter 2
1000 Terminal
51 mm (2 in.)
51 mm (2 in.)
25 mm (1 in.)
25 mm (1 in.)
Height mm (in.) Width mm (in.)
123 (4.86) 156 (6.15)
123 (4.86) 156 (6.15)
224 (8.8) 305 (12.00)
17
