Appendix A Electrical; Environmental - Rockwell Automation VICPAS PanelView Plus Compact 400 User Manual

Electrical

Environmental

Publication 2711PC-UM001A-EN-P - March 2009
Specifications
Attribute
400 and 600
Input voltage, DC
Power consumption, DC
1000
Input voltage, DC
Power consumption, DC
Attribute
Temperature, operating
Temperature, non-operating
Heat dissipation
400 and 600
1000
Relative humidity
Altitude, operating
Shock, operating
Shock, nonoperating
Vibration
Enclosure Ratings
Appendix
Value
24V DC nom (18...30V DC)
25 W max (1.0 A at 24V DC)
24V DC nom (18...32V DC)
70 W max (2.9 A at 24V DC),
39 W typical (1.6A @ 24V DC)
Value
0...55 °C (32...131 °F)
-25...70 °C (-13...158 °F)
85 BTU/hr
240 BTU/hr
5...95% without condensation
2000 m (6561 ft)
15 g at 11 ms
30 g at 11 ms
10...57 Hz, 0.012 pk-pk displacement
57...500 Hz, 2 g pk acceleration
NEMA Type 12, 13, 4X (Indoor use only),
IP54, IP65
A
117
