Chapter 2
Installing the Terminal
Product Dimensions
185 (7.28)
185 (7.28)
248
(9.7)
22
Product dimensions for each terminal are in mm (in.).
PanelView Plus 400 Keypad or Keypad/Touch Dimensions
152
(6.0)
PanelView Plus Compact 600 Touch Dimensions
152 (6.0)
PanelView Plus Compact 1000 Touch Dimensions
329
(12.97)
90
(3.54)
71 (2.81)
154 (6.08)
98 (3.86)
71 (2.81)
55 (2.18)
Publication 2711PC-UM001A-EN-P - March 2009
60
(2.35)
68 (2.68)
154 (6.08)
