Chapter Objectives
Cables for Runtime
Communication
PanelView Plus Compact Terminals to SLC Controllers
PanelView Plus Compact
Protocol
400, 600, 1000 Comm Port
DF1 RS-232 (DF1) Comm port (9-pin)
DH-485 RS-232 (DH-485) Comm port (9-pin)
EtherNet/IP EtherNet/IP Comm port
(1)
An EtherNet/IP direction connection between a PanelView Plus Compact terminal and an SLC 5/05 requires hub or crossover cable listed.
Protocol
DF1
DH-485
EtherNet/IP
(1)
AIC+ Module recommended for isolation when PanelView and controller are not using same power supply.
87Publication 2711PC-UM001A-EN-P - March 2009
Terminal Connections
This chapter provides network and device connections for the
terminals.
• Runtime communication cables
• Communication port isolation
• USB ports
• Serial connections on base unit
• Ethernet (onboard communication)
The tables provide a summary of terminal connections to controllers
and network interface modules for runtime communication.
Cables: PanelView Plus Compact Terminals to SLC Controllers
SLC-500, 5/01, 5/02
CH1 RJ45
(DH-485)
N/A
Use AIC+ module
(1761-NET-AIC)
Connect to port 1 or 2
N/A
PanelView Plus Compact Terminals to MicroLogix Controllers
MicroLogix 1500LRP
PanelView Plus Compact
CH1 (9-pin RS-232)
400, 600, 1000 Comm Port
2711-NC13 (5 m/16 ft)
RS-232 (DF1) Comm port (9-pin) 2711-NC14 (10 m/32 ft)
2706-NC13 (3 m/10 ft)
2711-NC13 (5 m/16 ft)
RS-232 (DH-485) Comm port (9-pin) 2711-NC14 (10 m/32 ft)
2706-NC13 (3 m/10 ft)
EtherNet/IP Comm port
SLC-5/03, 5/04, 5/05 SLC 5/03
CH0 (9-pin RS-232) CH1 (RJ45)
(DF1 or DH-485) (DH-485)
2711-NC13 (5 m/16 ft)
2711-NC14 (10 m/32 ft) N/A
2706-NC13 (3 m/10 ft)
2711-NC13 (5 m/16 ft) Use AIC+ module
2711-NC14 (10 m/32 ft) (1761-NET-AIC)
2706-NC13 (3 m/10 ft) Connect to port 1 or 2
Use 1761-NET-ENI module
N/A
with Ethernet cable
Cables: PanelView Plus Compact to MicroLogix Controllers
MicroLogix 1000, 1200, 1500LSP
CH0 (8-pin Mini DIN)
(DF1 or DH-485) (DF1 or DH-485)
2711-NC21 (5 m/16 ft)
2711-NC22 (15 m/49 ft)
(null modem not required)
2711-NC21 (5 m/16 ft)
2711-NC22 (15 m/49 ft)
(null modem not required)
Use 1761-NET-ENI module
with Ethernet cable
6
Chapter
SLC 5/04 SLC 5/05
CH1 (DH+) CH1 (ENET)
N/A N/A
N/A N/A
2711P- CBL-EX04 Ethernet
N/A
(1)
crossover cable
MicroLogix 1100, 1400
Ethernet Port
N/A
(1)
N/A
(1)
Ethernet cable
87
