Chapter 4 Configuring the Terminal
Name of application that is currently loaded.
Only appears if application is loaded.
32
Configuration Mode
Terminal Operation Description
Load Application (F1) Opens another screen where you can select an
application to load. Once loaded, the application name
will appear under Current Application.
Run Application (F2) Runs the .mer application displayed under Current
Application. An application must be loaded before you
can run it.
Application Settings (F3) Opens a menu of application-specific configuration
settings.
Terminal Settings (F4) Opens a menu of options to configure non-application,
specific terminal settings.
Delete Log Files Before Toggles between Yes and No. If you select Yes, all data
Running (F5) log files, alarm history and alarm status file will be
deleted before the application is run. If you select No, log
files are not deleted first.
Reset (F7) Resets the terminal. The action on startup depends on
how you configure the startup option.
Exit (F8) Exits Configuration mode.
Publication 2711PC-UM001A-EN-P - March 2009
