Appendix A Specifications

Display

Mechanical

118
Attribute
Display type
400 and 600 grayscale
400, 600, 1000 color
Display size, diagonal
400 grayscale
400 color
600
1000
Display area (WxH)
400 grayscale
400 color
600 grayscale and color
1000
Resolution
400 grayscale and 400 color
600
1000
Luminance (typical)
400 grayscale
400 color
600 and 1000 color
Backlight
400
600 and 1000
Touch screen
Actuation rating
Operating force
(1)
Keypad function keys
Actuation rating
Operating force
(1)
Number of function keys varies by terminal size.
Attribute
Weight, approx.
400 keypad or keypad and touch
600 touch
1000 touch
Dimensions, approx. HxWxD
400 keypad or keypad and touch
600 touch
1000 touch
Value
Grayscale passive matrix, film compensated
super-twist nematic (FSTN)
Color active matrix, thin-film transistor (TFT)
liquid crystal display (LCD)
3.8 in.
3.5 in.
5.5 in.
10.4 in.
77 x 58 mm (3.0 x 2.3 in.)
71 x 53 mm (2.8 x 2.1 in.)
112 x 84 mm (4.4 x 3.3 in.)
211 x 158 mm (8.3 x 6.2 in.)
320 x 240
320 x 240
640 x 480
2
120 cd/m Nits
2
200 cd/m Nits
2
300 cd/m Nits
LED
CCFL 50,000 hours life, min.
Analog resistive
1 million presses
10...110 g
Function keys, numeric and navigation
1 million presses
340 g
Value
562 g (1.24 lb)
789 g (1.74 lb)
2.9 kg (6.3 lb)
152 x 185 x 90 mm (6.0 x 7.28 x 3.54 in.)
152 x 185 x 98 mm (6.0 x 7.28 x 3.86 in.)
248 x 329 x 55 mm (9.77 x 12.97 x 2.18 in.)
