Chapter Objectives
Accessing Configuration
Mode
31Publication 2711PC-UM001A-EN-P - March 2009
Configuring the Terminal
This chapter shows how to use the Configuration mode of your
terminal to:
• perform data entry and navigation.
• load an application.
• run an application.
• modify application settings.
• modify terminal settings.
Your terminal has onboard software, FactoryTalk View ME Station, to
perform and configure terminal operations. When you reset or start
the terminal, you automatically enter Configuration mode, unless your
.MER application is automatically set to run on startup.
To access Configuration mode from a running application, press the
Goto Configuration Mode button. The application stops running but is
still loaded.
To access Configuration mode from a running application, you
IMPORTANT
must add a Goto Configuration Mode button to an application
screen in FactoryTalk View Studio software.
4
Chapter
31
