Chapter 8 Troubleshooting
Startup Information
Messages
Message # Displayed Message
(1) Video Initialized
37
30 Watchdog Test
1 RAM Test
(1) Stuck Key
31
Stuck Touch
(1)
31.5
(1) Battery Test
32
Registry Search
(1)
2.5
2 Image Search
(2) Downloading Image
11
(1) External CF
50
(2) Transfer Image
20
(1) Internal CF
23
24 CRC Check
(2) Decompress System
27
28 Starting System
29 System Check ###
29.1 System Check
(1)
The status number and message displays only on the 100 terminals.
(2)
The status number and message displays only on the 400 and 600 terminals.
108
Startup messages display in a specific sequence on the terminal during
startup and typically display for a few seconds. These messages
indicate the startup sequence of the terminal, but do not require that
you perform any action.
Description
Configures and initializes the graphics video system.
Tests the watchdog circuitry to verify system integrity.
Tests the RAM memory.
Checks the integrity of the function key hardware.
Checks the integrity of the touch screen hardware.
Checks the integrity of the battery hardware.
Locates and loads the most recent, valid registry. Multiple copies of the registry are
maintained. If power is lost during a registry update, a valid registry is available the next
time power is applied to the terminal.
Checks for new OS firmware upgrade on the external CompactFlash card and the serial port.
Downloads a new OS firmware upgrade to internal RAM. Message may remain on screen
for several minutes.
Transfers a new OS firmware upgrade from the external CompactFlash card to the terminal.
Message may display for several minutes.
Programs the OS firmware just downloaded into RAM. Message may remain on screen for
several minutes.
Programs the OS firmware just downloaded into the internal flash memory. Message may
display for several minutes.
Checks the integrity of the OS firmware.
Decompresses the compressed OS firmware into RAM.
Launches the operating system (OS).
Checks internal file system integrity (### is percent progress indicator).
Disables internal file system integrity check. Contact technical support.
Publication 2711PC-UM001A-EN-P - March 2009
