Serial Properties
Field Description
Device The serial device your terminal is connected
to.
Error Check Type of error checking used. Error checking is
automatically configured if Use Auto Config
is set to Yes.
Parity Type of parity used. The parity is
automatically configured if Use Auto Config
is set to Yes.
Stop Bits Number of stop bits used.
Ack Timeout Ack/Poll timeout value in ms.
Max Retries Maximum number of retries before the serial
driver fails.
Station Station number based on a specific device.
Baud Rate Data rate at which serial driver
communicates. The baud rate is
automatically configured if Use Auto Config
is set to Yes.
Use Auto Config Automatically or manually configures the
baud rate, parity, and error checking
parameters.
Com Port Communication port used on the terminal.
Configuring the Terminal Chapter 4
Valid Values
PLC_CH0
KF2
SLC_CH0
KF3
KFC
KFC15
AC_CH0
BCC, CRC
None, Odd, Even
1 or 2
20...60,000 ms
0...255
PLC_CH0 0...77 (octal)
KF2 0...77 (octal)
SLC_CH0 0...31
KF3 0...31
KFC 1...99
KFC15 1...99
AC_CH0 0...255
110
300
600
1200
4800
9600
19,200
38,400
115,200
Yes (auto configure)
No (manual configure)
1 (COM1)
2 (COM2)
