Startup Sequence

Publication 2711PC-UM001A-EN-P - March 2009
This flow chart provides a sequence of startup operations for the
terminal and shows system information messages that are displayed
on the terminal.
Display copyright message, bootcode versions and Testing... message
Initialize Video - Display 37 Video Initialized (1000 only)
Perform Power On Self Test
Display 30 Watchdog Test
Display 1 RAM Test
Display 31 Stuck Key (1000 only)
Display 31.5 Stuck Touch (1000 only)
Display 32 Battery Test (1000 only)
Display 2.5 Registry Search (1000 only)
Any POST failures?
Check for new OS
Display 2 Image Search
No
Do serial or external CF card download?
Serial or CF card Download of OS
Display 11 Download to RAM (400 and 600 only)
Display 50 External CF (1000 only)
Program OS into flash
Display 20 Transfer Image (400 and 600 only)
Display 23 Internal CF (1000 only)
Check OS integrity
Display 24 CRC Check
Decompress OS to RAM
Display 27 Decompress System (400 and 600 only)
Jump to OS
Display 28 Starting System
Perform final system check (1000 only)
Display 29 System Check or
Display 29.1 System Check (if skipping check)
Power On
Yes
No
Yes
Troubleshooting Chapter 8
Display Error...
message and HALT
109
