Chapter 7 Upgrading Firmware
98
6. Click Finish to copy the firmware source files to the location
specified in step 2.
If the files were created in a folder on a local hard drive, copy
TIP
the files to the root directory of the CompactFlash card.
Upgrade Firmware in Terminal with Firmware Upgrade Card
Follow these steps to upgrade the terminal firmware from a
CompactFlash card.
1. Insert the CompactFlash card into the card slot of a powered
terminal.
A dialog box indicates the firmware upgrade is about to occur.
2. Press Upgrade to begin the firmware upgrade.
Do not remove the CompactFlash card while the upgrade
IMPORTANT
is in process.
A dialog box reminds you to back up all .mer and user files
before upgrading the terminal.
3. Click Yes if you want to continue with the upgrade.
Publication 2711PC-UM001A-EN-P - March 2009
