Chapter Objectives
Product Overview
Catalog Number
Explanation
Cat. No.
2711PC-K4M20D
2711PC-B4C20D
2711PC-T6M20D
2711PC-T6C20D
2711PC-T10C4D1
9Publication 2711PC-UM001A-EN-P - March 2009
Overview
This chapter covers these topics:
• Product description
• Catalog number explanation
• Software support
• Terminal configurations
• Display modules
• Accessories
The PanelView Plus Compact terminals are similar to some PanelView
Plus terminal configurations but with limited hardware and software
functions. Major differences of the compact terminals include:
• Fixed hardware configuration, without the addition or
replacement of modular components.
• Serial and Ethernet communication only.
• Connection to a single logic controller using either RSLinx
Enterprise or KEPServer Enterprise software, not both.
• Limited number of displays and alarms in the FactoryTalk View
Machine Edition (ME) application and runtime software.
• FactoryTalk ViewPoint software is not supported.
• Primary HMI for CompactLogix controllers.
Applications created for PanelView Plus Compact terminals are
TIP
referred to as Compact Machine Edition applications. You can
run compact applications on PanelView Plus and PanelView
Plus Compact terminals. You cannot run a regular Machine
Edition application created for a PanelView Plus terminal on a
PanelView Plus Compact terminal.
The table provides catalog number configurations for the PanelView
Plus Compact terminals.
Display Size
Operator Input
Keypad
4 inch
Keypad and Touch
6 inch
Touch
10 inch
Touch
Chapter
Display Type
Input Power
Monochrome
Color
Monochrome
DC
Color
Color
1
9
