Command File / Save project deletes additional serialization file, if the file exists, associated
with currently saved project.
File / Save project
This option is used for saving project file, which contains settings of device configuration and
buffer data saved. Data saved to project file can be restored anytime by menu command File
/ Load project.
The dialog Save project contains three additional windows in Project description panel
placed at the bottom of dialog Save project. The windows are for displaying information
about currently selected project file in dialog Save project and information about current
project, which has to be saved. Dialog Save project contains also additional checkboxes
and button with picture of key displayed.
The first checkbox named "Set Protected mode of software after loading of this project
file" and button with key are used to save project in special mode called Protected mode.
Clicking on the button with key displayed, password dialog appears which is used to specify
Protected mode password of recently saving project. Projects saved with active Protected
mode checkbox and password are special projects also called Protected mode projects. For
more detailed information about Protected mode projects see Options / Protected mode.
The second checkbox named "Require project file checksum before first programming"
has special function. When the checkbox is checked, program Pg4uw will ask user for
entering correct project checksum before allowing to start the first device programming. The
checkbox has effect after loading of project file, which was saved with the checkbox checked.
Usage of the checkbox is recommended for additional check, that correct project file is
recently loaded. There is also recommended to use this checkbox along with active Protected
mode (the first checkbox "Set Protected mode of software after loading of this project file"
checked).
Project information consists of:
• manufacturer and name of the first device selected in the project
• date and time of project creation
• user written description of project (it can be arbitrary text, usually author of project and
some notes)
The first (upper) window contains information about currently selected project file in dialog
Save project.
The second (middle) windows displays information about actual program configuration
including currently selected device, active programmer, date, time. These actual program
settings are used for creation of project description header.
The third (bottom) window is user editable and contains project description (arbitrary text),
which usually consists of project author and some notes.
File / Reload file
Choose this option to reload a recently used file.
When you use a file, it is added to the Reload file list. Files are listed in order depending on
time of use of them. Lastly used files are listed before files used far off.
