• For all supported devices see actual Device list on
I.C. Tester
• TTL type: 54,74 S/LS/ALS/H/HC/HCT series
• CMOS type: 4000, 4500 series
• static RAM: 6116.. 624000
• user definable test pattern generation
Package support
• support all devices in DIP with default socket
• package support includes DIP, SDIP, PLCC, JLCC, SOIC, SOP, PSOP, SSOP, TSOP,
TSOPII, TSSOP, QFP, PQFP, TQFP, VQFP, QFN (MLF), SON, BGA, EBGA, FBGA,
VFBGA, UBGA, FTBGA, LAP, CSP, SCSP etc.
• support devices in non-DIP packages up to 48 pins with universal adapters
• programmer is compatible with third-party adapters for non-DIP support
Programming speed
BeeProg2
Device
Am29DL640G (parallel NOR Flash)
K8P6415UQB (parallel NOR Flash)
K9F1G08U0M (parallel NAND Flash)
QB25F640S33 (serial Flash)
AT89C51RD2 (microcontroller)
PIC32MX360F512L (microcontroller)
Conditions:
BeeProg+
Device
M50FW080 (parallel Flash)
MX28F640C3BT (parallel Flash)
K9F1G08U0M (parallel NAND Flash)
AT45D081 (serial Flash)
AT89C51RD2 (microcontroller)
PIC18LF452 (microcontroller)
Conditions:
SOFTWARE
• Algorithms: only manufacturer approved or certified algorithms are used. Custom
algorithms are available at additional cost.
• Algorithm updates: software updates are available regularly, approx. every 4 weeks, free
of charge. OnDemand version of software is available for highly needed chips support
and/or bugs fixes. Available nearly daily.
• Main features: revision history, session logging, on-line help, device and algorithm
information
Device operations
• standard:
• intelligent device selection by device type, manufacturer or typed fragment of part name
• automatic ID-based selection of EPROM/Flash EPROM
Size [bits]
400080Hx16 (64 Mega)
400100Hx16 (64 Mega)
8400000Hx8 (1 Giga)
800200Hx8 (64 Mega)
10000Hx8
80000Hx8
P4, 2,4GHz, 512 MB RAM, USB 2.0 HS, Windows XP
Size [bits]
100000Hx8 (8 Mega)
400000Hx16 (64 Mega)
8400000Hx8 (1 Giga)
108000Hx8 (16 Mega)
10000Hx8
4000Hx16
P4, 2,4GHz, 512 MB RAM, USB 2.0 HS, Windows XP
