• Verify operation can report errors also in case of protected devices, that have active read
protection of data.
Device / Program
This command allows to programming of the all device or its part by the data of the buffer.
The control program reports a result of this action by a write of an error message to INFO
window.
The menu command Device / Device options / Operation options allows to set another
working area as the standard, and set other operation options for programming process
control.
Device / Erase
This command allows erasing the whole programmable device. The program reports the end
without error or end with the error by writes the warning report on the display.
The Blank check procedure is applied after Chip erase command for such chips, where
doesn't exist other way how to check, the chip is really erased.
Device / Test
This command executes a test with device selected from list of supported devices (e.g. static
RAM) on programmers, which support this test.
Device / IC test
This command activates a test section for ICs separated by type to any libraries (on
distribution CD). First select an appropriate library, wished device and then a mode for test
vectors run (LOOP, SINGLE STEP). Control sequence and test results are displayed to LOG
WINDOW. In case of need is possible to define the test vectors directly by user. Detailed
description syntax and methods of creation testing vectors is described in example_e.lib file,
which is in programs installation folder. Note. Because the rising/falling edges of
programmers are tuned for programming of chips, it may happen the test of some chips fails,
although the chips aren't defective (counters for example).
Device / JAM/VME/...Player
Jam STAPL was created by Altera® engineers and is supported by a consortium of
programmable logic device (PLD) manufacturers, programming equipment makers, and test
equipment manufacturers.
The Jam™ Standard Test and Programming Language (STAPL), JEDEC standard JESD-71,
is a standard file format for ISP (In-System Programming) purposes. Jam STAPL is a freely
licensable open standard. It supports programming or configuration of programmable devices
and testing of electronic systems, using the IEEE 1149.1 Joint Test Action Group (JTAG)
interface. Device can be programmed or verified, but Jam STAPL does not generally allow
other functions such as reading a device.
The Jam STAPL programming solution consists of two components: Jam Composer and Jam
Player.
